FPC/FFC Flexible Flat Cable 0.5/1.25/1.0 Pitch 20p Cable Flat Wire
Welding Soft Cable
Product introduction
FFC Flexible Flat Cable (FFC) is a new type of data cable made of
PET insulating material and extremely thin tinned flat copper wire,
which is pressed through a high-tech automation equipment
production line. Thin thickness, small size, simple connection,
easy disassembly, easy to solve electromagnetic shielding (EMI) and
other advantages
Flexible Flat Cable(FFC) can arbitrarily choose the number and
spacing of wires, make the connection more convenient, greatly
reduce the volume of electronic products, reduce production costs,
and improve production efficiency. It is most suitable for moving
parts and motherboards, PCB board to PCB board, miniaturization
Used as data transmission cable in electrical equipment.Common
specifications are 0.5mm, 0.8mm, 1.0mm, 1.25mm, 1.27mm, 1.5mm,
2.0mm, 2.54mm and other flexible cables with various pitches.
Parameter:
| Pin number | 2-120 |
| Brand Name | SYH |
| Maximum outer diameter of wire | 21(mm) |
| Insulation thickness | 012 (mm) |
| Sheath material | PE |
| Pitch | 0.5 mm/1.0mm/1.25mm |
| Connectors | Customized |
| Wire | Customized |
| Wire length | 300mm or According to the customers' requirements |
| Wire Color | Customized |
| Certification | ISO9001, T/S16949, Rohs |
| MOQ | Small quantity can be accepted |
| Sample | Sample can be provided for evaluating |
| Sevice | OED ODM accepted |
| Delivery Time | 3-15 days upon receipt of payment |
| Packaging | 00/200/300/500pcs per bag , then outside carton |
| Test | Professional breakover and pulling force test before goods sent out |
Flexible flat flexible cable:
① PITCH (Pitch): 0.5mm 0.8mm 1.0mm 1.25mm 1.27mm 2.0mm 2.54mm
② Conductor specifications: 0.035*0.030, 0.035*0.65, 0.05*0.5,
0.05*0.065, 0.1*0.65, 0.1*0.8;
③ Number of cable screens: 2P-120P;
④ Cable length: 15mm-Nm;
Two types of film are commonly used:
① Rated voltage and temperature 60V 80℃ AWM 20624 80C 60V VW-1
② Rated voltage and temperature 60V 105℃ AWM 20624 105C 60V VW-1
Common models are as follows:
Type A:The two ends are connected and the reinforcing plate is
pasted on the insulating tape;
Type B :The reinforcement board is pasted directly on the
insulating adhesive paper;
Type C :The reinforcing plates at both ends are directly pasted on
the conductor;
Type D :The reinforcing plates at both ends are pasted directly on
the conductor;
Type E:One end of the reinforcement board is attached to the
insulating adhesive paper, and the other end is directly soldered;
Type F :The reinforcing plates at both ends are directly attached
to the insulating adhesive paper, and the internal half is peeled
off;
Type G :Direct soldering at both ends.
