4G Full Frequency LET Cabinet Antenna LCD Display Module Integrated
Machine Antenna Patch Antenna
Product introduction
About Patch Antenna:
Patch antenna is a pie-shaped directional antenna, suitable for
covering a single layer of small offices, small shops and other
access points can not be placed in a central indoor location. The
patch antenna produces a hemispherical coverage surface, which
propagates from the installation point, and the propagation range
is between 30 degrees and 180 degrees.
Patch antennas are also called panels, flat panels, or microstrip
antennas. They are composed of two metal plates (one of which is
larger than the other), with a sheet-like dielectric in the middle.
This antenna is usually installed in white or black plastic, which
not only protects the antenna, but also facilitates installation.
Because they are flat, thin and lightweight, patch antennas are
often hung on walls or ceilings.
Parameters:
| Place of Origin | Jiangsu,China |
| Brand Name | SYH |
| Model Number | SYH-H003 |
| Frequency | 700-2700Mhz |
| Connector | SMA male |
| V.S.W.R | ≤2.0 |
| Gain | 5dbi |
| Antenna length | 115.4*21.6mm |
| MOQ | Small quantity can be accepted |
| Sample | Sample can be provided for evaluating |
| Sevice | OED ODM accepted |
| Delivery Time | 3-15 days upon receipt of payment |
| Packaging | One product with one PE bag packaging , then outside carton |
| Test | 100% tested before goods sent out |
Commonly used antenna types:
(1) External glue stick antenna: good performance, no need to
debug, easy to replace, high gain, suitable for various terminal
equipment.
(2) SMT patch type: The commonly used ceramic antenna has a small
footprint, high integration, and is easy to replace. It is suitable
for products with small space requirements, but this type of
antenna is slightly more expensive and has a smaller bandwidth.
(3) On-board PCB antenna: It is etched by PCB, with low cost, but
with limited performance and good adjustability. It can be used in
large quantities for Bluetooth and WiFi wireless communication
modules.
(4) FPC antenna: connected by feeder, it is free to install and has
high gain. It can usually be pasted on the non-metal casing of the
machine by using adhesive.
☀ Our wifi antennas can be made in different gains and frequency,
if you need, we can accept customized.
☀ Our wifi antennas can be made with different connectors such as
sma connectors, tnc connectors and n connectors.
☀ We can also produce GSM antennas, indoor or out door panel
antennas, sucker antenna and so on.
☀ If you need, we can also customized cable assembly used in antnna
like sma to IPEX/UFL cable assemblies. For this product, please
contact our sales deparment and get more details.
☀ If you require a special antenna not found here, you can create
your own antenna by calling our sales department.
